Summarized Features and Benefits:

• High energy density in a smaller footprint - 1/4 the size & 1/6 the weight of a comparable Lead Acid battery. Expect reduced transportation costs vs the typical Lead Acid battery.
• Industrial case design is rugged and durable, and easy to stack and bolt together for any commercial requirements. The battery can also function up to 140F to accommodate various environments and applications.
• Up to 3X Extended Shelf Life and up to 5X longer field operating time than a comparable Lead Acid Battery with broader environmental operation
• Designed for ease and flexibility in installation - allows for series or parallel connection. It can be stacked, placed side-by-side, and be bolted together ensuring ease of installation and secure battery attachment.
• Charges up to 5 times faster than comparable Lead Acid battery.
• Compatible charge controllers or charge/ inverters are available from 3rd party vendors.
• Engineered with high capacity and top quality Panasonic/Sanyo battery cells, and an integrated Battery Management System to ensure safe optimal performance.

Specifications:

• Max: 16.8V Nominal: 14.8V Minimum 12V
• 104Ah (160 Cell configuration)
• Max. discharge current: 40A
• Peak current: 50A for 30 seconds
• Max. charge current: 25A
• Depth of discharge: 70%
• Cycles: 3000
• Bolt Size: M8
• Connector Type: IP68 waterproof 6-pin, M14 panel type, cable connector.
• Communication: SMBus
• Operating Temperature: -20C to 60C Charging 10C to 45C
• Dimensions and Weight: 306mm x 186mm x 185mm 9Kg/20lbs
• Certifications: UN38.3, UL 1642
• Limited Warranty*: 5 years or 3000 cycles (whichever occurs first)
• Energy Retention: 60% at 5 years following initial installation date
