Primary Ultra High Energy Density Lithium Battery: D Size 3.6V 19 Ah (ER34615 / SAFT LSH20 ) With Wires (non Rechargeable) (DGR)

Primary Ultra High Energy Density Lithium Battery: D Size 3.6V 19 Ah (ER34615 / SAFT LSH20 ) With Wires (non Rechargeable) (DGR)

add to cart

Primary Ultra High Energy Density Lithium Battery: D Size 3.6V 19 Ah (ER34615 / SAFT LSH20 ) With Wires (non Rechargeable) (DGR)

SKU:
P/N 30311

SKU:
30311
Rechargeable:
No
Battery Size:
ER34615 (D)
Chemistry:
Lithium
Voltage (V):
3.6V
Button Top:
No
For Pack Building:
No
Chemistry:
Lithium-Thionyl
Capacity(mAh):
19000
Brand:
Tenergy (Tech)
Battery Bundle:
1-pack
Single Cell or Pack:
Single Cell

Special Order/Contact Us - Minimum Order Quantity: 10K

saved: $0
x

Sales Tax

Tenergy only collects sales tax on orders shipped to addresses in the States of California.

You may be responsible for state and local sales/use taxes when filing your tax returns. Please check your local sales tax laws.

Order now to ship in 1 Business Day

product highlights

  • Ultra High Energy Density D sized Primary Lithium Thionyl Chloride battery
  • Perfect battery choice for powering wireless alarm, security systems, industrial meters, memory backup for computers, night vision equipment and other devices need long-lasting batteries.
  • Lithium Thionyl Chloride battery technology provides the highest energy density, three times higher than Alkaline (Zinc Manganese Dioxide) batteries.
  • Widest operating temperature range of -76F to + 185 F, ideal for rough security, industrial and field applications
  • Ultra low self discharge at less than 1% per year at +68F, enabling an effective shelf life of 10 years.
  • Non-flammable electrolyte.
  • Compatible with Saft LS 33600 Lithium cell
  • UL Recognized --- BBCV2.MH48285.
  • Passed UN transportation tests (T1-T8).
  • Pre-soldered wires for easily making battery packs or other connections

Summarized Features and Benefits:

  • Chemistry: Lithium-thionyl Chloride (Li-SOCl2) technology
  • Nominal capacity: 19 Ah ( 19,000 mAh)
  • Operating temperature range: -55C / +85C
  • Diameter (max): 34.2mm(1.4 in)
  • Height (max): 61.5mm(2.46 in)
  • Typical weight: 110g (3.6 oz)
  • Ultra High Energy Density D sized Primary Lithium Thionyl Chloride battery
  • Perfect battery choice for powering wireless alarm, security systems, industrial meters, memory backup for computers, night vision equipment and other devices need long-lasting batteries.
  • Lithium Thionyl Chloride battery technology provides the highest energy density, three times higher than Alkaline (Zinc Manganese Dioxide) batteries.
  • Widest operating temperature range of -76F to + 185 F, ideal for rough security, industrial and field applications
  • Ultra low self discharge at less than 1% per year at +68F, enabling an effective shelf life of 10 years.
  • Non-flammable electrolyte.
  • Compatible with Saft LS 33600 Lithium cell
  • UL Recognized --- BBCV2.MH48285.
  • Passed UN transportation tests (T1-T8).
  • Pre-soldered wires for easily making battery packs or other connections

Specifications:

  • Chemistry: Lithium-thionyl Chloride (Li-SOCl2) technology
  • Nominal capacity: 19 Ah ( 19,000 mAh)
  • Open circuit voltage: (at +20C +68F) 3.66V
  • Nominal voltage: (at 1mA +20C +68F) 3.6V
  • Max. Continuous current: 200mA Max
  • Pulse current: Up to 400mA
  • Storage (recommended): +30C +86 F max
  • Operating temperature range: -55C / +85C
  • Diameter (max): 34.2mm(1.4 in)
  • Height (max): 61.5mm(2.46 in)
  • Typical weight: 110g (3.6 oz)

Applications:

  • Radio communication equipments and other military electronics
  • Building alarms, monitoring and security systems
  • Industrial and residential metering systems
  • Emergency location transmitters and Beacons
  • Global Positioning Systems (GPS)
  • Computer or server memory back up
  • LED lighting devices
  • Sonobuoys
  • Compatible with and replaces SAFT LSH20 battery with over 40% more energy

Warnings:

  • This battery is a non-rechargeable battery. DO NOT CHARGE THE BATTERY!
  • Do not use if the battery casing is damaged.
  • Please discharge the battery for a few minutes with 100mA.
  • Don't use different models of battery in series.
  • This is not a high drain battery, please don't use it for the applications with discharging current > 200 mA!
  • The storage area should be clean, cool (not exceeding +30 Deg C ), dry and ventilate
