Product Highlights
- Nominal Voltage: 3.6V
- 70A Max Continuous Discharge Current
- Gravimetric Energy Density: 220 Wh/Kg
- Volumetric Energy Density: 580 Wh/L
Product Specifications
- Nominal Voltage: 3.6V
- Capacity:
- Typical: 4,000 mAh
- Gravimetric Energy Density: 220Wh/Kg
- Volumetric Energy Density: 580Wh/L
- Discharge Current:
- Max continuous: 70A
- Max Pulse : 70C
- Charge Current:
- Continuous:2.5C
- Max: 10C
- Operation Temp Range
- Discharge: -40 to 80℃
- Charge: -20 to 60℃
- Weight: 67g
- Dimensions:
- Max Diameter: 21.35mm
- Max Height: 70.30mm
Notes:
- This battery is only available, as a cell option, for a battery pack that is designed and incorporated, by Tenergy. Contact us with your application details.
