Tenergy Polymer Li-ion Battery 3.7V 140mAh (232535)

Tenergy Polymer Li-ion Battery 3.7V 140mAh (232535)

Out of Stock

Tenergy Polymer Li-ion Battery 3.7V 140mAh (232535)

SKU:
P/N 30655-0

SKU:
30655-0

Min. Order Qty: 5,000+

saved: $0
x

Sales Tax

Tenergy only collects sales tax on orders shipped to addresses in the States of California.

You may be responsible for state and local sales/use taxes when filing your tax returns. Please check your local sales tax laws.

Out of Stock

Expected Availability: Special Order Only

Product Highlights

  • Prismatic Polymer Li-ion Battery
  • Voltage: 3.7V
  • Capacity: 140mAh

Features

  • Battery Chemistry: Polymer Li-ion
  • Nominal Voltage: 3.7V
  • Minimum Capacity: 140mAh (0.2C Discharge)
  • Max. Charge Current:
    • 0℃~15℃ = 0.2C
    • 15℃~25℃ = 0.5C
    • 25℃~45℃ = 1C
  • Max. Discharge Current:
    • -10℃~15℃ 0.2C
    • 15℃~60℃ 1C
  • Standard Discharge Current.: Constant current 0.2C end voltage FD
  • Weight: Approx: 3.5g
  • Dimension (Max): 25.0 x 35.5 x 2.3mm (W x H x T)

Warnings

  • CAUTION: when working with Li-ion cells, they are very sensitive to charging characteristics and may explode if mis-handled. User should have enough knowledge on Li-ion rechargeable batteries in charging, discharging and assembly before use. We are not responsible for any damage caused by misuse or mishandling of these Li-ion batteries

Download Datasheet:
pdf-manual
